System Format
3-way

Sensitivity (2.83v @ 1m, Free-Field)
88.5 dB

Sensitivity (2.83v @ 1m, Installed)
N/A

Recommended Amplifier Power (RMS into 4 Ohm, Music Signal)
130 – 600 W

Continuous Power Handling (CTA 426-B)
300 W

Nominal Impedance
4 Ohms

Minimum Impedance (20Hz to 20kHz)
4 Ohms @ 150 Hz

Drive Unit Complement
2 x 8” (203 mm) HDT C-CAM Bass Drivers
1 x 3” (76 mm) HDT C-CAM Mid-Range Driver
1 x MPD III Tweeter

Frequency Response Free-Field (-6dB)
44 Hz – 60 kHz

Frequency Response, In-Room (-6dB)
25 Hz – 60 kHz

Maximum Peak SPL (AES75, Z-weighted)
122 dB

Bass Alignment
HiVe II Ported

Port Tuning Frequency
33 Hz

Crossover Frequency
LF/MF: 700 Hz
MF/HF: 2.6 kHz

External Dimensions with all accessories fitted (H x W x D)
1155 x 383 x 475 mm (451/2 x 151/16 x 1811/16”)

Weight (each)
26.5 kg (58 lb 7 oz)

Sold As
Pair
