TECHNICAL SPECIFICATIONS
Preamplifier section

Input impedance ( Balanced input )
47Kohm
Maximum input level
10 Volt RMS
Noise floor ( 1Vrms, 20 - 20 kHz, balanced)
-135 dB
THD + N (1Vrms, 20 - 20 kHz, balanced)
<0.004%
Gain (Balanced)
0 dB


Amplifier section

Output Impedance
< 0,02 Ohm
Frequency response
1 – 150 kHz
Channel separation
> 120 dB
THD ( 20 - 20 kHz)
< 0.004%
Maximum peak current
>100A
Damping factor 8 ohm load
>350
I Input sensitivity 120W output
1.3Vrms
Input sensitivity HT 120W output
1Vrms
Gain HT Input
x36 (31 dB)
Rated output power

8 ohms
2 x 125 W
4 ohms
2 x 200 W
2 ohms
2 x 370 W
Power consumption
110 W
Standby
1W
(no load or signal)



Dimensions

Width
470 mm / 18.3 inches
Depth ( with a speaker terminals)
430 mm / 16,9 inches
Height
128 mm / 5 inches
Weight
20,5 Kg / 45 lbs.
