Frequency Response

80 Hz — 35 kHz

Sensitivity (1W@1M)

87 dB

Nominal Impedance

6 ohms

Power Handling (RMS)

100 W

System Power Handling (RMS)

150 W

Recommended Amplifier Requirements

40 — 150 W

Maximum SPL

107 dBa

Bass Alignment

Bass reflex - Front ported

Drive Unit Complement

2 x 4" (100 mm) C-CAM cone bass/mid driver
1 x 1" (25 mm) C-CAM Gold Dome tweeter

Cabinet Dimensions (H x W x D)

140 x 610 x 67 mm (51/2 x 24 x 25/8")

Cabinet Dimensions (Including Grille and Terminals (H x W x D))

140 x 610 x 77 mm (51/2 x 24 x 31/16")

Cabinet Dimensions (Including Grille and Bracket (H x W x D))

140 x 610 x 84 mm (51/2 x 24 x 35/16")

Pre-Construction Bracket

Dedicated bracket included

Weight

4.2 kg (9 lb 4 oz)

Sold As

Single Unit
