System Format
3-way

Sensitivity (2.83v @ 1m, Free-Field)
87.5 dB

Sensitivity (2.83v @ 1m, Installed)
N/A

Recommended Amplifier Power (RMS into 4 Ohm, Music Signal)
130 – 500 W

Continuous Power Handling (CTA 426-B)
250 W

Nominal Impedance
4 Ohms

Minimum Impedance (20Hz to 20kHz)
3.9 Ohms @ 165 Hz

Drive Unit Complement
2 x 6” (152 mm) HDT C-CAM Bass Drivers
1 x 3” (76 mm) HDT C-CAM Mid-Range Driver
1 x MPD III Tweeter

Frequency Response Free-Field (-6dB)
64 Hz – 60 kHz

Frequency Response, In-Room (-6dB)
54 Hz – 60 kHz

Maximum Peak SPL (AES75, Z-weighted)
121 dB

Bass Alignment
Sealed

Port Tuning Frequency
N/A

Crossover Frequency
LF/MF: 800 Hz
MF/HF: 2.7 kHz

External Dimensions with all accessories fitted (H x W x D)
205 x 537 x 335 mm (81/16 x 211/8 x 133/16”)

Weight (each)
15.3 kg (33 lb 12 oz)

Sold As
Single Unit
