Lower Frequency Limit
20 Hz (Typical IEC room)

Upper Frequency Limit
40 – 120 Hz variable

Low Pass Filter Alignment
Active 4th order 24 db/octave

Amplifier Output
500 W continuous

Amplifier Classification
Class-D amplifier with switched-mode power supply (SMPSU)

Bass EQ Profiles
1: Movie
2: Music
3: Impact

Phase Control
0 & 180 degrees

Auto Sensing
Line Level >2 mV

Input Level Requirements
Standby after 20 minutes if no signal sensed

Drive Unit Complement
1 x 12" C-CAM subwoofer driver featuring triple suspension and 3" long throw voice coil

Trigger Input
5 – 12 V via 3.5 mm mono mini-jack socket

Cabinet Dimensions (Excluding Grille and Terminals (H x W x D))
340 x 340 x 380 mm (133/8" x 133/8" x 1415/16”)

Dimensions (Including Grille, Amp and Feet)
370 x 340 x 410 mm (149/16" x 133/8" x 161/8”)

Mains Input Voltage
110 – 120 Vac /
220 – 240 Vac 50/60 Hz (Electronically Auto selected)

Power Consumption
400 W / 0.5 W in Standby (ErP approved)

Weight (unpacked)
20.1 kg (44 lb 5 oz)

Sold As
Single Unit
