System Format
3 - way

Frequency Response, In-Room (-6dB)
31 Hz - 35 kHz

Sensitivity (2.83v @ 1m)
87.5 dB

Nominal Impedance
8 Ohms

Minimum Impedance
4.0 Ohms @ 160 Hz

Maximum SPL (single, free-field)
110 dB

Power Handling (RMS)
200 W

Recommended Amplifier Requirements
80 - 200 W

Crossover Frequency
L.F: 750 Hz
M.F/ H.F: 2.8 kHz

Port Tuning Frequency
40 Hz

Bass Alignment
Bass reflex
Dual HiVe II port system

Drive Unit Complement
2 x 6" C-CAM RST II bass driver
1 x 3" C-CAM RST II mid-range driver
1 x 1" (25 mm) C-CAM Gold Dome tweeter with UD Waveguide II

External Dimensions (Including Grille and Terminals (H x W x D))
1000 x 185 x 332 mm (393/8 x 75/16 x 135/64")

External Dimensions (including Outrigger Feet and Spikes (H x W x D))
1045 x 274 x 389 mm (419/64 x 1025/32 x 155/16")

Weight (each)
19.3 kg (42 lb 9 oz)

Sold As
Pair
