SPECIFICATION

NOMINAL IMPEDANCE
4 ohms
RECOMMENDED AMPLIFIERS
20 to 180 watts
FREQUENCY RESPONSE
28Hz-30kHz
SENSITIVITY
90 dB linear for 1 watt at 1 metre
BASS /MIDRANGE DRIVERS
2x 6.5” bass/mid units. One driver with Pagina Mica cone and open weave dust cap and one driver with polypropylene cone with soft polypropylene dust cap. Both units working in tandem.
TWEETER
ProAc 1” silk dome tweeter
CROSSOVER
Specially designed crossover to accommodate two different types of bass/mid cones. Glass fibre board with finest components using multistrand copper wire designed for use with both Bi-amping and Bi-wiring.
HEIGHT (CABINET)
978mm on spikes(38.5”)
WIDTH (CABINET)
193mm (7.6”)
DEPTH (CABINET)
229mm (9”)
WEIGHT
26kg each (55lb)
MODE
Stand mounting
GRILLE
Acoustically transparent crimplene
STANDARD FINISHES
Black Ash, Mahogany, Cherry, Oak, Silk White and Walnut
PREMIUM FINISHES
Rosewood, Ebony. *Premium Finishes to order at extra cost*
