SPECIFICATION

NOMINAL IMPEDANCE
8 ohms
RECOMMENDED AMPLIFIERS
20 to 150 watts
FREQUENCY RESPONSE
30Hz-30kHz
SENSITIVITY
88.5 dB linear for 1 watt at 1 metre
BASS /MIDRANGE
ProAc 165mm (6.5”) ProAc unit with Excel magnet system, glass fibre wave cone and copper phase plug.
DOME TWEETER OPTION D2D
ProAc 25mm (1”) silk dome air cooled and inner damping. Mirror image offset.
RIBBON TWEETER OPTION D2R
The ProAc ribbon tweeter has a ribbon lighter than a human hair with rear chamber damping and alnico magnet.
CROSSOVER
Finest components on dedicated circuit board. Multistrand oxygen free copper cable throughout. Split for optional Bi wiring or Bi amplification
HEIGHT (CABINET)
430mm (17”)
WIDTH (CABINET)
203mm (8”)
DEPTH (CABINET)
260mm (10.25”) including grill thickness of 12mm
WEIGHT
each 11Kg (24lb)
MODE
Stand mounting
GRILLE
Acoustically transparent crimplene
STANDARD FINISHES
Black Ash, Mahogany, Cherry, Walnut, Oak, Silk White.
PREMIUM FINISHES
Rosewood, Ebony. *Premium Finishes to order at extra cost*
